ABB OTE16T3M, Langallinen, 3P, Muovi, IP65, Valkoinen, Liettua

Tuotenumero: [1427297] | Valmistaja: ABB | Mallinum: 1SCA022613R2190 | EAN: 6417019199658 | UNSPSC.: 39122233 | EL-nr.: 2119001956
Etävarastossa
Tuotetta on etävarastossamme. Toimitusaika noin 3-4 työpäivää.
Toimitusvaihtoehdot  - Valitaan kassalla
Budbee Laatikko - Nouda valitsemastasi laatikosta!
Ilmainen toimitus
Bring - Toimitus huoltopisteeseen
7,02
Bring - Kotiinkuljetus -arkisin.
15,12
Toimituskulut on laskettu vastaanottajan postinumeron perusteella:00180 - Helsinki Vaihda postinumero
Syötä postinumero toimitusta varten: Tallenna
EUR 95,26
ilman ALV 75,90
Kokonaishinta sis. toimitus 95,26
Lue lisää teknisistä tiedoista
EMC safety switch, 3-p. 415V AC23 16A, 7.5kW. Mounted auxiliary contact: 1NO0NC. Plastic enclosure. IP65. Black Selector handle. Interlocked cover. Defeatable interlocking. The enclosure in the OTE series is using a rigid glass reinforced polycarbonate enclosure. The enclosure is UV protected, protected against low-pressure water jets (IP65), and hence built for outdoor and indoor use. The cable entries are threaded and have knock out holes for 2 parallell cables and one control cable, both from top and bottom. The handle is padlockable and made for three padlocks. The interlocking can be by-passed, for thermographing etc. The switch is made for 5 wire system, and have a fixed neutral terminal and PE terminal. The EMC protection is utilized by a metal plate in the bottom, connected to the cable shield with clamps, included in the delivery. No EMC glands needed.
